5-14 l Maintenance
Cleaning the Volatile Trap on the
Demister (D1300 -5000)
1 Stop the dryer and lockout the main power.
2 Remove the thumbscrews then remove the volatile demister carriage and demister
from its housing.
3 Remove the demister screen from the demister carriage by pushing it out towards
the right side of the carriage.
4 Clean the assembly using a mild soap and water. Let the assembly dry
thoroughly before installation.
NOTE: In cases of heavy volatiles, steam cleaning, pressure washing or the use of solvents, such
as acetone, may be necessary. Be sure to test a small area with the solvent you have selected to
be sure there is no adverse reaction.
5 Insert the demister carefully back into the demister carriage and then replace the
entire assembly back into the demister housing.
6 Inspect the condition of the gasket. If it is damaged, replace the gasket.
7 Secure the cover in place using the original thumbscrews.
