Typical Applications (continued)
Model Drying Temperature Range
Low temperature (with precooler)* 100° - 150°F {38° - 66°C}
High heat (with aftercooler)* 150° - 375°F {66° - 191°C}
Low-high (with aftercooler & precooler)* 100° - 375°F {38° - 191°C}
* See Installation: Connecting the Aftercooler and Precooler of this User Guide for more
information.
• Throughput rates of 600 to 5000 lbs {271 to 2267 kg} per hour (some
materials can be run at a higher rate).
• Dewpoints of -40°F {-40°C}.
Use the aftercooler when:
• Throughput rates are less than 50% of the dryer’s rated capacity.
• You are pre-drying material at temperatures over 150°F {66°C}
• The return air is 120°F {49°C} or above.
NOTE: The aftercooler reduces the temperature of air returning from the drying hopper, improving
the efficiency of the desiccant.
0
NOTE: All Carousel Plus D Series 600+ Dryers use an aftercooler located after the process blower.
0
2
Description
Description l 2-3
