Replacing the Desiccant Wheel (D1300 - 5000)
When desiccant becomes clogged or contaminated, you should replace the desiccant wheel to ensure
optimum performance.
1 Stop the dryer, disconnect and lockout the main power.
2 Remove the upper side panels from both sides of the dryer.
3 Remove the side panels from both sides of the desiccant wheel assembly housing by re-
moving the securing bolts.
