Descriptio n l 2-9
Specifications: MDCW Carousel Plus
Dryers (continued)
6 in.
{15.2 cm}
1.625 in. dia.
{4.1 cm}
through hole
6 in.
{15.2 cm}
4 in.
{10.2 cm}
1.625 in. dia.
{4.1 cm}
through hole
4 in.
{10.2 cm}
TLR Tube Loader
(machine loader)
Outlet - 2 in. dia. {5.1 cm}
F
E
TLR Tube Loader
(hopper loader)
Outlet - 2 in. dia. {5.1 cm}
Inlet - 1.5 in. dia. {3.8 cm}
E - Receiver dia.
4.5 in. {11.4 cm}
F - Height with
viewing chamber
1 lb.
22 in. {55.9 cm}
2 lb.
27 in. {68.6 cm}
H
G
Inlet - 1.5 in. dia. {3.8 cm}
G - Receiver dia.
4.5 in. {11.4 cm}
H - Height
17.5 in. {44.5 cm}
Loader Base Plates
Application Notes:
When to use high-heat models
You should select the high-heat dryer if you are drying at temperatures over 180°F {82°C}. High-heat
models are equipped with high-temperature heaters and insulated process hose.
When to use the aftercooler
The aftercooler reduces the temperature of the air returning from the drying hopper, improving the
efficiency of the desiccant. You should use the aftercooler if:
! You are batch drying at temperatures over 160°F {71°C}.
! Throughput rates are less than 50% of the dryer’s rated capacity.
When to use additional filtration
The standard return air cartridge filter is sized for the airflow of each dryer model and is suited for most
applications. You should consider adding an optional dust collector and/or volatile trap if:
! The material contains excessive fines. An additional dust collector or cyclone will extend the time
between cleaning.
! The material produces volatiles during drying which condenses into a waxy or oily residue, a volatile
trap will help to protect the desiccant.
2
Description
TPDS020-0705-REV
