Installa tion l 3-13
Checking for Proper Air Flow (continued)
4 Press the Stop button. Reconnect the process filter that was discon-
nected in Step 3.
5 If the airflow is incorrect, disconnect the power, follow the proper lockout
procedure, and swap any two of the three main power wires.
WARNING: All wiring, disconnects, and fuses should be installed by qualified electrical technicians in
accordance with electrical codes in your region. Always maintain a safe ground. Do not operate the equip-
ment at power levels other than what is specified on the the machine serial tag and data plate.
Inlet
Process
Filter
3
Installa tion
LEADS
To Next Page
