Function
4-14 l Operati on
Screen
SCREEN 11 (Dewpoint control
and/or Dewpoint monitor)
SCREEN 12 (MAIN MENU)
SCREEN 13
SCREEN 14
DRYER STATUS
PROC REGEN OTHER
DRYER PROCESS
STATUS SCREEN
Control Function Descriptions(continued)
The dewpoint control will automatically
adjust regeneration temperature to main-
tain dewpoint setpoint. Dewpoint control
is not active with -40° F {-40° C} setpoint.
NOTE: Dewpoint actual will not be live for
approximately 5 to 8 minutes.
This is the dryer MAIN MENU. It can be
located by pressing the MENU key while
at the DEFAULT screen. By pressing the
Select Category buttons under the titles,
the user goes to STATUS screens, SETUP
screens, or DIAGNOSTIC screens.
This is the Dryer Status screen. It can be
found by pressing the Select Category
button under the word "Stat" on the Main
Menu (screen 12). Any information under
the status section is read only. NO
CHANGES can be made from the status
sections. The operator can select to see
status information for Process,
Regeneration, or Other.
This is a column title screen. To navigate
to screens within a column (reference the
flow charts beginning on page 4-4), the
operator must use the scroll buttons,
“Prev” or “Next”. The “Next” button
will scroll one screen at a time down a list
of screens. Once the last screen in the list
is displayed the “Next” button will return
the operator back to this Title screen.
When the “Prev” button is pressed, it will
scroll one screen at a time up the list of
screens. Once the title screen is displayed
the “Prev” button will go up to the next
high screen, in this case the Dryer Status
screen 13.
PROCESS DEW POINT
ACT -40°F SET -40°F
DRYER MAIN MENU
STAT SETUP DIAG
✐
