Function
4-20 l Operati on
Control Function Descriptions(continued)
Screen
SCREEN 35
SCREEN 36
SCREEN 37
SCREEN 37
SCREEN 38
SCREEN 38
SCREEN 39
PANEL INSIDE TEMP
ACT 100°F
DRYER SETUP
PROC ALM DISP OTHER
SETUP PROCESS
PROC REGEN OTHER
SETUP PROCESS
PROC PROPID RETPID
PROCESS TEMPERATURE
RANGE 100°F - 450°F
This screen shows the temperature inside
the control enclosure. It is measured at the
lower right corner of the control board.
This is the Dryer Setup screen. It can be
found by pressing the Select Category but-
ton under the word Setup on the Main
Menu (screen 12). By pressing the Select
Category buttons under the titles, the user
can select to see setup information for
Process, Alarms, Display, or Other.
This is the Setup Process screen. It can
be found by pressing the Select Category
button under the word "Proc" on the Dryer
Setup (screen 36). By pressing the Select
Category buttons under the titles, the user
can select to see setup information for
Process, Regeneration, or Other.
This is the second Setup Process screen.
It can be found by pressing the Select
Category button under the word "Proc" on
the Setup Process screen (37). By pressing
the Select Category buttons under the
titles, the user can select to see setup infor-
mation for Process, Process PID, or Return
Air PID if the aftercooler flow control is
installed. Note: When configured as a cen-
tral dryer, you will not see the Process
PROPID.
This screen shows the allowable tempera-
ture range for setpoint temperatures. With
the proper password (see page 4-32,
screen 85), this range can be narrowed.
NOTE: Software may allow
the Process temperature
setpoint limit up to 450
°F
{232
°C}, however Conair does
not recommend a setpoint
limit over 375
°F {191°C} due
to nuisance alarms.
✐
NOTE: To avoid nuisance
alarms Conair recommends
that the low setpoints be set
to 150
°F {66°C} or above.
✐
NOTE: Conair is not responsi-
ble for damage caused by
excessively high drying
setpoints that are not in
accordance with your drying
material recommendations.
✐
To Next Page
