6
.
Software Utilities
52
PC-686BX(NLX)
-LV,
PC-686BX(NLX)
-LVV
Table 6
.6
.
Data Format Table for Temperature Sensor 2
Temperature
TEMP<8:1>
TEMP<0>
+125°C
7Dh
0
:
:
:
+25°C
19h
0
:
:
:
+1°C
01h
0
-0.5°C
00h
1
+0°C
00h
0
-0.5°C
FFh
1
-1°C
FFh
0
:
:
:
-25°C
E7h
0
:
:
:
-55°C
C9h
0
58
60
Table of Contents
Default Chapter
2
Trademarks
2
Product Configuration
3
Table of Contents
4
1 Introduction
8
Features
8
Limited Three-Years Warranty
9
How to Obtain Service
10
Liability
10
Warning
10
Handling Precautions
10
Structure of this Manual
11
2 Specifications
12
Functional Specifications
12
General Specifications
13
Power Management
14
Power Supply Requirements
16
Power Consumption
16
Board Component Names
17
Block Diagram
18
3 Hardware Description
20
Installation Procedure
20
CPU Installation
21
Main Memory Installation:dimm1 and DIMM2
22
Sdram
22
Parallel Port Connector: CN1
23
Serial Port Connector: CN2/CN3
24
RS-485 Specifications
25
USB Connector: CN4
26
Keyboard Connector: CN11
27
PS/2 Mouse Connector: CN6
28
LAN Connector: CN12
28
LCD Connector: CN5
29
VGA Connector: CN7
30
CPU Fan Connector: CN9
30
External Battery Connector: CN10
31
4 Jumper Settings
32
Watchdog Timer Output Selector: JP6
32
RS-232C/422/485 Selector Switch: JP1/JP2
33
Transmit Data Control for Half-Duplex Mode
33
Jumper Setting
34
I/O Addresses and Commands
35
RS-422/485 Terminating Resistance: JP3
35
On-Board LAN Selector: JP7
36
Disk on Chip Memory Address Selector: JP4
36
Display Type Setting: JP5
37
CMOS Memory Erase: JP8
38
On Board VGA Selector: JP9
38
POWER Supply AT/ATX Selector: JP10
39
LED Display
39
5 CPU Board Resources
40
I/O Map
40
Memory Map
41
DMA Channels
41
PCI Configuration Space Map
42
Interrupts
42
PCI Interrupt Routing Map
43
6 Software Utilities
46
Intel 440BX Chipset Driver
46
INF Installation Utility
46
Graphics Driver
47
Driver Support
47
LAN Driver
48
Watchdog Timer (WDT) Setup
50
Upgrading the BIOS to a New Version
51
Hardware Monitoring
52
7 BIOS Setup
60
Main Menu
63
Standard CMOS Setup
65
BIOS Features Setup
68
Chipset Features Setup
72
Integrated Peripherals
76
Power Management Setup
79
Pnp/Pci Configuration Setup
83
Defaults Menu
86
Load BIOS Defaults
86
Load SETUP Defaults
86
Supervisor/User Password Setting
86
Exit Options
88
POST Messages
89
POST Alarm Tones
89
Error Messages
90
POST Codes
96
8 Available Accessories
102
