Contec SBC Series User Manual

7. BIOS Setup
PC-686BX(NLX)-LV, PC-686BX(NLX)-LVV
59
Selection from Main Menu
The following selections can be made from the main menu.
Table 7.2. Main Menu Selections
Date mm : dd : yy
Sets the system date. The day of week changes
automatically as you enter the date.
Time hh : mm : ss Sets the system time.
IDE Primary Master
The options are displayed in a sub-menu.
(Described in Table 7.3.)
Press the <Enter> key and select from the
detailed options displayed in the sub-menu.
IDE Primary Slave
The options are displayed in a sub-menu.
(Described in Table 7.3.)
Press the <Enter> key and select from the
detailed options displayed in the sub-menu.
IDE Secondary Master
The options are displayed in a sub-menu.
(Described in Table 7.3.)
Press the <Enter> key and select from the
detailed options displayed in the sub-menu.
IDE Secondary Slave
The options are displayed in a sub-menu.
(Described in Table 7.3.)
Press the <Enter> key and select from the
detailed options displayed in the sub-menu.
Drive A
Drive B
None
360K, 5.25 in
1.2M, 5.25 in
720K, 3.5 in
1.44M, 3.5 in
2.88M, 3.5 in
Select the type of floppy disk drive installed in
the system.
Video
EGA/VGA
CGA 40
CGA 80
MONO
Select the default video device.
Halt On
All Errors
No Errors
All, but Keyboard
All, but Diskette
All, but Disk/Key
Select the conditions in which the BIOS should
halt the POST process and notify the user.
Base Memory N/A
Displays the base memory detected when
booted.
Extended Memory N/A
Displays the extended memory detected when
booted.
Total Memory N/A
Displays the total size of memory available to
the system.
Item Options Description
