7. BIOS Setup
PC-686BX(NLX)-LV, PC-686BX(NLX)-LVV
73
Max. Power Saving
Performs maximum power management. Sleep mode = 1 hour, standby
mode = 1 hour, suspend mode = 1 hour, HDD power off = 15 minutes
Min. Power Saving
Performs minimum power management. Only available on SL CPUs.
Sleep mode = 1 minute, standby mode = 1 minute, suspend mode = 1
minute, HDD power off = 1 minute
User Define
Each mode can be set individually. When this option is enabled, each
mode can be set in the range 1 minute to 1 hour. However, the setting
range for HDD power off is 1 minute to 15 minutes.
PM Control by APM
Enabling this setting activates the advanced power management device and extends
maximum power saving mode to halt the CPU internal clock.
This setting changes to "No" if maximum power saving mode is disabled.
Video Off Method
This setting controls how to blank the monitor.
V/H SYN.C..+Blank
This option causes the system to disconnect the power to the vertical
and horizontal sync ports and blanks the video buffer.
Blank Screen This option simply blanks the video buffer.
DPMS Initial power management signal for display
Usually please set “DPMS”.
Video Off After
Setting "Enabled" sets the VGA adapter to power saving mode.
N/A Monitor remains on even in power saving mode.
Suspend Monitor display goes blank when the system goes to suspend mode.
Standby Monitor display goes blank when the system goes to standby mode.
Done Monitor display goes blank when the system goes to any power saving mode.
MODEM Use IRQ
Specifies the interrupt request (IRQ) assigned to the system’s modem (if installed).
The system wakes up if an interrupt occurs on the specified IRQ.
Selection options: NA, 3, 4, 5, 7, 9, 10, 11
Types of Power Management
The four modes described below are Green PC power management functions. Values
can only be set for these fields when "User Defined" power management is specified.
See the explanation above for details of the available setting values.
