Press E to select. The screen will show: Output 1.
2 If necessary, select the required output port (
Output 1 to Output 4) using the
scroll keys (A or C) and then press E to select. The screen will show the cur-
rently selected option: OFF (default).
3 Use the scroll keys (
A or C) and then E, to select any of the following options:
OFF The output remains off at all times.
Message Waiting This output type activates when the SD3 has a Mes-
sage waiting and de-activates once the Message has
been played.
Remote Access This output activates when the SD3 is being accessed
remotely with a touch-tone telephone. The output de-
activates when call has finished.
Temperature High This output activates when the Temperature High set-
ting has been reached. The output de-activates once
the temperature falls below the preset temperature
(see Alarm Levels).
Temperature Low This output activates when the Temperature Low set-
ting has been reached. The output de-activates once
the temperature rises above the preset temperature
(see Alarm Levels).
Listen Active This output type activates when the SD3 is using the
Listen In feature (see Listen-in & talkback mode).
Speech Active This output type activates when the SD3 is using the
Talk Back feature (see Listen-in & talkback mode).
Phone Line Fault This output type will activate when telephone line con-
nected to the unit has a fault, i.e. line disconnected or
no line voltage after 50 seconds.
PSTN In Use This output type activates when the SD3 is using the
fixed telephone line.
GSM In Use This output type activates when the SD3 is using the
mobile telephone link.
Call Active This output type activates when the SD3 is active, i.e.
after the unit has been triggered. The output de-acti-
vates once the unit has dialled all its contacts or the
call is aborted.
Call Successful This output type activates when the SD3 has delivered
its message successfully. The output de-activates
when the unit is next triggered.
Call Failed This output type activates when the SD3 fails to deliver
its message. The output de-activates when the unit is
next triggered.
Remote Control 1-4 These output types can be remotely turned on and off
by a touchtone telephone. e.g., switching on lighting or
heating/ventilation systems.
Supply Volts Low This output type activates when the SD3 supply volt-
age drops below 10.5 Volts. (see Alarm Levels).
GSM Signal Low This output type activates when the GSM signal level
falls below the level set in the Signal Low option. (see
Alarm Levels).
