Telephone (TNV) connections
The easiest way to connect the SD3 to the telephone line is to use the telephone
lead that is provided with the unit as shown below:
3
2
1
6
5
4
A
B
A1
B1
Cable type 1/0.5 CW1308
BT Master Jack (NTE5)
User accessible connections
To other telephone
extension sockets
However, if the lead is not long enough or a serial connection is required the SD3
can be hard wired to the telephone socket as shown below:
