Test Line
This test menu allows you to test the SD3’s fixed telephone line (not GSM mobile)
status.
To test the line
1 From standby, enter the user code, then use the scroll keys (A or C) or 0 to
display the Test Options menu:
Test Options
Press E to select. The screen will show the first option: Test Messages.
2 Press
C or press 4 to show: Test Line.
3 Press
E to select. The screen will show either: LINE OK or LINE FAIL, as ap-
propriate.
4 Press
F to exit.
Test Supply
This test menu allows you to test the SD3’s supply voltage.
To test the supply voltage
1 From standby, enter the user code, then use the scroll keys (A or C) or 0 to
display the Test Options menu:
Test Options
Press E to select. The screen will show the first option: Test Messages.
2 Press
C or press 5 to show: Test Supply.
3 Press
E to select. The screen will show the voltage level: e.g. 11.8V.
Note: The voltage level must be between 10.5V and 28V, however, the voltage
reading will not exceed 25.5V.
4 Press
F to exit.
GSM Phone Utilities
These utilities allow you to check various aspects of GSM operation, when the
optional GSM module is fitted.
To use GSM phone utilities
1 From standby, enter the user code, then use the scroll keys (A or C) or 0 to
display the Test Options menu:
Test Options
Press E to select. The screen will show the first option: Test Messages.
2 Press
C or press 6 to show: GSM Phone Utils.
3 Press
E to select. The screen will show the first option: Make Call.
4 Use the scroll keys (
A or C) and then E, to select any of the following options:
Make Call Allows you to enter a number and make a call via the
GSM link. The SD3 will act like a hands free mobile
phone.
Signal Strength This is the equivalent to the bars on a mobile phone.
GSM Number This is the telephone number of the SIM card. This
feature is not available with all SIMs.
IMEI Number This is the International Mobile Equipment Identity
which uniquely identifies the GSM Module.
IMSI Number This is the International Mobile Subscriber Identity
which uniquely Identifies the SIM.
Module Type This is the type of GSM Module fitted. Cooper Security
may supply different GSM Modules.
Call Provider This is the service provider, for example Vodafone,
Orange, O2 etc.
