IDC 255 Progate Drive Thru Service Manual
© 2006-2013, IMI Cornelius Inc. - 9 - Publication Number: 621057419SER
Programming (Changing) the Ice Portion
To change the size of any of the four ice dispense sizes follow the steps below.
1. To enter the program mode press the Progr
am Button
and Desired Size button at the same
time and hold for 5 seconds.
2. The Ice Portion Bar will come on
3. Press the RIGHT ARROW button to increase the amount of dispensed ice. The LED will move
towards the right indicating the Ice Portion has been increased.
4. Press the LEFT ARROW button
to decrease the amount of dispensed ice. The LED will move towards
the left indicating the Ice Portion has been decreased.
5. To exit the program mode press the Desired Size button
or wait 10 seconds and the control will
return to the dispense mode.
6. Place a cup under the ice chute and press the just programmed dispense size button
If amount dis-
pense amount is not the desired amount repeat the process.
7. To exit, repeat Step 1.
Agitation Time
The software coding for the progate system involves a direct relationship between the dispense time and the agita-
tion time.
Dispense Time (mS) Agitation Ratio
Agitation Time (mS)
50 10 500
70 10 700
90 10 900
110 10 1100
130 10 1300
150 10 1500
170 10 1700
190 10 1900
210 10 2100
230 10 2300
Dispense Time (mS) Agitation Ratio Agitation Time (mS)
50 16 800
70 16 1120
90 16 1440
110 16 1760
130 16 2080
150 16 2400
