IDC 255 Progate Drive Thru Service Manual
© 2006-2013, IMI Cornelius Inc. - 3 - Publication Number: 621057419SER
UNIT SPECIFICATION
DESCRIPTION
The Ice Drink Cornelius (IDC) series of dispensers solves your ice and beverage service needs in a sanitary, space
saving, economical way. Designed to be manually filled with ice from any remote ice–making source, these dis-
pensers will dispense cubes (up to 1–1/4 inch in siz
e), cubelets, and compressed (not flaked). In addition, the units
include beverage faucets, a cold plate, an internal carbonator tank and an external pump for the carbonator, and
are designed to be supplied direct from syrup tanks with no additional cooling required.
VALVE CONFIGURATIONS
• IDC 255 Progate Drive Thru Unit with 7 Intelli Valves and 1 Variety Valve
• IDC 255 Progate Drive Thru Unit with 8 Intelli Valves
• IDC 255 Progate Drive Thru Unit with 8 UFB-1 Valves
SPECIFICATION
Model Descriptions IDC 255
B=Beverage
C=Coldplate
H=Internal Carb
P=Progate
Z=No Drip Tray
Unit Weight 368 Pounds
Ice Storage 255 Pounds
Maximum Number of Faucets 10
Built-in Cold Plate Yes
Electrical 120/1/60
9.3 Amps of Total Unit Draw
OR
220/1/50
4.7 Amps of Total Unit Draw
Dimensions Width 29.90 inch (.76 m)
Height 39.75 inch (1.0 m)
Depth 36.90 inch (.94 m)
CO
2 Operating Pressure 75-psig (max)
Water 100 psi (7 bar) maximum static pressure.
40 psi (2.8 bar) minimum dynamic pressure.
3/8” minimum water line recommended.
To Next Page
