Ice Portion Bar
The portion bar is used to determine the amount of time programmed for each size button. Each button has a min-
imum and maximum amount of time that can be programmed. If a button cannot be adjusted to the size desired use
a
nother button to get the desired results.
Figure 6.
=20mS
50mS
230mS
“S” Small
80mS
260mS
“M” Medium
150mS
330mS
“L” Large
230mS
410mS
“XL” XLarge
