Cornelius PRISM - Page 13

3/18-16 Hex Head Bolt
Pan Head Phillips 8-32
Punch Tool
Front Die
Rear Die
Knockout adapter plate
Screws - 2 Qty
Knockout kit P/N-629097803
P/N 620069489
Prism Owner’s Manual
© 2018, Cornelius Inc. - 9 - Publication Number: 548000096
Figure 11.
629097803 – KNOCKOUT KIT BOM 629097803 – KNOCKOUT KIT: SERVICE PARTS
Part Number Description Qty Part Number Description
620070512 Punch Tool 1 620070512 Punch Tool
620069490_Front Die Front Die 1 620069489 Knockout Adapter Plate
620069490_Rear Die Rear Die/Receiver 1
620069490_Screws 8-32 Pan head
Phil
lip Screws
2
620069490_Bolt 3/18-16 Hex Head
Bolt
1
620069489 Knockout Adapter
Plate
5
