Cornelius PRISM - Knock out Kit

Prism Owner’s Manual
Publication Number: 548000096 - 8 - © 2018, Cornelius Inc.
KNOCK OUT KIT-P/N 629097803
NOTE: All Enduro Cold Carbonation units since 2004 have panels that will accept the Prism Valve.
Models:
ED150BCH, 150BCHZ, ED175BCH, ED175BCHZ, ED200BCH, ED200BCHZ, ED250BCH,
ED250BCHZ, ED300BCH and ED300BCHZ
NOTE: All Enduro Ambient Carbonation and Beverage Only units
prior to November 2018 will require
the punch tool.
All Enduro Units since November 2018 have panels that will accept the PRISM
valve
Beverage Only Models:
ED150B, ED150BZ, ED175B, ED175BZ, ED200B, ED200BZ, ED250B, ED250BZ,
ED300B and ED300BZ
Ambient Carbonation Models:
ED150BC, ED150BCZ, ED175BC, ED175BCZ, ED200BC, ED200BCZ, ED250BC,
ED250BCZ, ED300BC and ED300BCZ
NOTE: All IDC Units (Serial #: 62C0912JD002) since 2009 have panels that will accept the Prism Valve.
Front Die
Rear Die
Punch tool
P/N 620070512
Figure 10.
