Prism Owner’s Manual
© 2018, Cornelius Inc. - 19 - Publication Number: 548000096
CONNECTION DIAGRAM
DIP SWITCH
LEVER SWITCH
OPTIFILL
POWER IN
SYRUP 2SYRUP 1
SYRUP 3
WATER
Figure 34.
3. Rotate both the spindles in the direc-
tion shown to secure the lock pin in
po
sition and also to open the flow
path of the drink.
Figure 33.
Closed
Condition
Open
Condition
