Cornelius PRISM - Installation Instructions; Knock out Adapter Plate; Knock out Adapter Plate and Tubing

Prism Owner’s Manual
Publication Number: 548000096 - 12 - © 2018, Cornelius Inc.
INSTALLATION INSTRUCTIONS
Sheet Metal adapter plate
for mounting prism valve
KNOCK OUT ADAPTER PLATE - P/N 620069489
Figure 19.
KNOCK OUT ADAPTER PLATE AND TUBING
Table 4
1. Align knock out adapter plate with 4 holes of valve mounting panel from “Front Side”.
Syrup 2
Syrup 3
Panel-Rear side
Panel-Front Side
Syrup 1
Front View
Plain / Carbonated
Water
Figure 20.
.
