Prism Owner’s Manual
© 2018, Cornelius Inc. - 15 - Publication Number: 548000096
2. Assemble all the lines with L - fittings
on to the knock out adapter plate and
Figure 25.
3. Align the back block inlet ports to the
L- fittings and fasten back block to the
valve panel using screws removed
earlier (Use either existing screws or
screws provided in the kit).
Figure 26.
