5. Gently push the valve body against
back block, until rear surface of the
valve body is flush with the back
block.
Figure 29.
6. Lock the valve body and back block
together with lock pin. Refer to
Table 8 on page 18.
Figure 30.
Prism Owner’s Manual
© 2018, Cornelius Inc. - 17 - Publication Number: 548000096
