Item No. Part No. Description
1 620069122 Valve Body Assy.
2 620069122A Valve Body
3 620069122B Valve Body Plug
4 620069522 Plate Valve Base
5 620056417 Back Block Assy
6
560003252 Lever Valve Optifill
560003193 Lever Valve Self Serve
7 84996001
Flow Control Bonnet
Assy
8 620069310
Screw #8-18 X 1/2 Type
2
5 410 SS
9 620070153
Plate Retaining Prism
Valve
10 71860292 Retainer Ring
11 60245001
Flow Adjustment Screw
FFV
12 31525030 O-ring .174 ID 103CS
13 60247
Bonnet FFV Flow
Cont
rol
14 31525007 O-ring .488 ID 103CS
15 48258005 Spring Syrup
16 60281002 Piston Syrup FFV
17 60281001 Sleeve Syrup FFV
18 740001883 O-Ring
19 60280002 Piston Water FFV
20 48258006 Spring Water
21 620069126W Water Solenoid Assy
22 620069126S Syrup Solenoid Assy
23 183008000 O-ring .489 ID 070 CS
24
620069127-
30
1
Front Cover Assembly
Black OP/SL/PB
25 620057622 Screw #8-18 X 3/8
26 620069124 Optifill Probe
27 620069125 Lever Return Spring
28 620069311 Screw #3-24 X 3/8
Item No. Part No. Description
29 620069584 Micro Switch
30 183184000 O-ring 1.17 ID 103 CS
31 620069283 Diffuser Assy
32 311086000 O-Ring.929 ID 070 CS
33 620069559 Diffuser
34 620069120 O-Ring .551 ID 070 CS
35 620069121 Nozzle Black
36 1950 Cover Valve Black
37
629097802
Installation Kit (Not
sh
own in Fig.42)
311908000
Oeitker Clamp #11.3
(
Not shown in Fig 42)
620709073
1/4 Dole L Fitting (Not
sh
own in fig 42)
620709068
1/4 Barb Fittings X1/4
SS (Not
shown in fig 42)
620717791
265 IDX42096” tube
(No
t shown in fig 42)
620700602
Mounting Screw (Not
sh
own in fig 42)
38
629097803
Knockout Kit (Not
sh
own in fig 42)
620069489
Knockout Adapter Plate
(No
t shown in fig 42)
620070512
Knockout punch Tool
(No
t shown in fig 42)
39
620070508
Coke Decal (Not shown
in fig
42)
620070509
Pepsi Decal (Not shown
in fig
42)
620070510
Generic Decal (Not
sh
own in fig 42)
Prism Owner’s Manual
