STANDARD RECOMMENDED PROCEDURE 003-876 | ISSUE 1 | JANUARY 2012 | PAGE 18 OF 21
As seen in Figure 21, open the front and rear doors.
Slide the covers apart to remove them from the housing.
Remove the following parts from the housing
a. Remove all the slack management clips by rotating them 180-degrees either direction, then
lifting them out of the sliding tray.
b. Remove the transitional strain-relief holder by pressing in on the back tab and lifting the
holder up 90-degrees from the sliding tray.
c. Remove all panels, then remove panel clips by pulling the clip away from the panel clip
holders and sliding the clips towards the front of the housing.
Insert the rear stacker into the housing by sliding the clips located on the bottom of the
stacker into the slots located in the sliding tray.
NOTE: When installing the stackers into a CCH-02U or CCH-03U housing, the stackers may be mounted
on top of one another using the directions in Step 6.
Assemble external strain-relief assembly depending upon the direction from which cable
enters the housing. Refer to Section 5.3.1 for details.
NOTE: Alternatively, a Universal Cable Clamp may be attached to the strain-relief arm to hold the cable.
Install the rst cassette on the right (as seen from the rear of the housing), either from the
front or rear of the housing between the stacker and side wall of shelf until it snaps into
place. To remove the cassette, press in on the two tabs and slide the cassette towards either
the front or the rear of the housing.
NOTE: Mate the recessed channel along the side of the cassette with the corresponding rails of the shelf
and stacker as you insert the cassette.
Install the second cassette on the left. Ensure the cables are not in a location to be pinched
when the door is closed.
