 SECURITY
 Covers
The covers can be locked in place to prevent
unauthorized access. Insert screws from the
hardware kit into both sides of the housing at the
locations depicted in Figure 24 to prevent the
covers from being removed.
Figure 24
 
Insert screws from the hardware kit into both sides
of the housing at the location depicted in Figure 25
to prevent the shelf from sliding in or out of the
housing.
Figure 25
 Doors
An optional lock kit (pn CCHA-LOCK-KIT) may be installed in the front and rear doors to prevent
unauthorized access. Follow the instructions provided with the kit.
Insert Screw to Lock
Cover in Open Position
Insert Screw to Lock
Cover in Closed Position
TPA-3984
Location for Screw Insertion
to Lock Sliding Shelf
TPA-3985
