STANDARD RECOMMENDED PROCEDURE 003-876 | ISSUE 1 | JANUARY 2012 | PAGE 4 OF 21
2.2. CCH-02U
• (1) Closet Connector Housing with blank adapter panels as seen in Figure 1
• (1) Hardware Kit containing:
(2) Screws, #6 - 32 x .312-inch (for locking the shelf)
(4) Screws, 12-24 x .50-inch (for rack-mounting)
(4) Screws, 4-24 x .312-inch (for locking the covers)
(8) Cable ties, 1/8 x 4 inches, white
(4) Cable ties, 8-inch, black
(4) CCH Labels, 1.35 x 4-inches
(1) External strain-relief bracket with (2) #6 - 32 x .25-inch screws
2.3. CCH-03U
• (1) Closet Connector Housing with blank adapter panels as seen in Figure 1
• (1) Hardware Kit containing:
(2) Screws, #6 - 32 x .312-inch (for locking the shelf)
(4) Screws, 12-24 x .50-inch (for rack-mounting)
(4) Screws, 4-24 x .312-inch (for locking the covers)
(8) Cable ties, 1/8 x 4 inches, white
(4) Cable ties, 8-inch, black
(6) CCH Labels, 1.35 x 4-inches
(1) External strain-relief bracket with (2) #6 - 32 x .25-inch screws
3. 
3.1. Tools
• Phillips-head screwdriver
• Pliers
3.2. Materials
The following materials may be required, depending upon your application. These items are ordered
separately. Contact your customer services representative for assistance.
• Connector Panels (CCH-CPXX-YY)
• Grounding Kit (FDC-CABLE-GND)
• Additional Internal Strain-relief Brackets (CCH1-STRN-INT)
• Additional External Strain-relief Assembly (CCH1-STRN-EXT)
• Transitional Strain-relief Holder, 2-pk (CCHA-CLIP-BTF-2)
• Housing Lock Kit (CCHA-LOCK-KIT)
• CCH-01U Recess Mount Kit, for 5 housings (CCH1-RECESS-KIT-5)
• CCH-02U Recess Mount Kit, for 5 housings (CCH2-RECESS-KIT-5)
• CCH-03U Recess Mount Kit, for 5 housings (CCH3-RECESS-KIT-5)
• Mounting ears for 23-inch applications (CDF-0XU-23)
• Central member strain-relief kit, 10-pack (CPP-SSR-KIT)
• Universal Cable Clamp (UCC) Kit (UCC-001)
• Buffer Tube Fan-out Kit (FAN-XX-YY)
