CORNING CCH-01U - Routing Jumpers (Patch Cords); Routing Jumpers; Documentation; Record Keeping

STANDARD RECOMMENDED PROCEDURE 003-876 | ISSUE 1 | JANUARY 2012 | PAGE 20 OF 21
7. 
 Open front door to access adapter panels.
 Remove dust caps from the connectors
and adapters into which they will be
mated. Clean the connector end faces and
adapters per standard company practices
and insert the connectors into the adapters.
 Install jumpers as specied by company
planning diagrams.
 Route the jumpers through the clips at the
front of the housing. The ap on front of
the guide allows jumpers to be inserted or
removed as a bundle or individually.
8. DOCUMENTATION
Accurate recordkeeping is imperative for an organized installation.
• Record ber identication information directly on the clear label cards (Figure 23) or on the provided
identication labels (or Avery label #5162 [1
1
/
3
x 4-inch]) which can be adhered to the label cards.
The label card can be removed by bowing the card and pulling it out the front of the housing.
• A white space inside the front door provides a location for a panel identication label to be placed
inside the door. The textured cover prevents unauthorized viewing of the panel identication from
outside the housing.
• Place a housing identication label (or Avery label #5162 [1
1
/
3
x 4-inch]) on the outside of the front
door. A crop mark near the left latch allows alignment of housing identication labels for aesthetic
purposes.
Figure 23
Flap
TPA-3982
Label Card
Location for Panel
Identification Label
Location for Housing
Identification Label
TPA-3983
