Wavecard-Waveport User Manual Coronis Systems
The periodic wake-up having to occur when waiting of synchronization, are
memorized (in order to preserve the periodicity), but not carried out.
At the end of the the wake-up phase, the transmitter modules sends a synchronization sequence, followed by
the data to be transmitted.
3.2.2 Examples of different wake-up conditions
Typical case (Long WakeUp = receiver WakeUp period + 100 ms):
Case where wake-up is too short (lower than the receiver's WakeUp period):
CS-SUP-MUTI-WPORTAPP-E04 20
