Wavecard-Waveport User Manual Coronis Systems
Appendix III – Parameter list
Parameter
number
Description Value Size
(bytes)
0x00
AWAKENING_PERIOD
RF radio medium polling period, in multiples of 100 ms
Period in multiples of 100 ms
(by default, 0x0A for one second)
0 = nearly continuous reception (every 20 ms)
1
0x01
WAKEUP_TYPE
Wake-up type used during frame transmission
0: long Wake Up (default setting)
1: short Wake Up = 50 ms
1
0x02
WAKEUP_LENGTH
Duration of wake-up when long wake-up is used
This value must be higher than the RF polling period. Value
in multiples of 1 ms, defined LSB first
Default value: 1100 ms
Min. value = 20 ms (0x1400)
Max. value = 10 sec. (0x1027)
2
0x03
WAVECARD_POLLING_GROUP
Byte containing the Wavecard's polling group number.
Byte 1: Polling_Group
by default, Polling_Group = 0x00
1
0x04
RADIO_ACKNOWLEDGE
Indicates whether or not radio frames must be
acknowledged by the receiver.
0: no acknowledgement
1: acknowledgement used (default value)
1
0x05
RADIO_ADDRESS
Radio board address
This value assigned at the factory. Read-only. 6
0x06
RELAY_ROUTE_STATUS
Parameter related to relay route transmission in each
relayed frame received.
0x00: Relay route transmission deactivated
0x01: Relay route transmission activated
By default, Relay route transmission deactivated
1
0x07
RELAY_ROUTE
Table containing the radio of successive repeaters used to
to reach an end-point.
BYTE 1: number of repeaters in route
Maximum number of repeaters = 3
If BYTE 1 != 0
BYTES 2 - 7: First repeater radio address, etc.
1 to 19
0x08
POLLING_ROUTE
Table containing the list of radio address to be queried.
BYTE 2 : number of modules to query
IF BYTE 2 != 0
BYTES 3 to 8 : radio address of the first module,
etc.
1 to 241
0x09
GROUP_NUMBER:
Byte containing the group number of the modules to
address in radio polling mode.
Group number
By default, GROUP_NUMBER = 0x00
1
0x0A
POLLING_TIME
Delay between two transmissions in polling mode
Value in multiples of 100 ms
By default, POLLING_TIME = 0x0A
1
0x0C
RADIO_USER_TIMEOUT
Time-out used for receiving a response frame
Value in multiples of 100 ms
Default value = 0x14 (2 seconds)
1
0x0E
EXCHANGE_STATUS
Parameter related to activation or error and/or status frame
management.
0: status and error frame deactivated
1: error frame activated
2: status frame activated
3: both status and error frames activated
By default, EXCHANGE_STATUS = 0x00
1
0x10
SWITCH_MODE_STATUS:
Automatic selection of RF communication mode used to
address a module using its radio address
0: automatic selection deactivated
1: automatic selection activated
Default value, SWITCH_MODE_STATUS =
0x01
1
0x16
WAVECARD_MULTICAST_GROUP
Byte containing the Wavecard's multicast group (available
starting with firmware v2.00).
By default, no group selected = 0xFF 1
0x17
BCST_RECEPTION_TIMEOUT
time-out for receiving CSMA frame following a
REQ_SEND_BROADCAST command transmission
(available starting with firmware v2.01)
Value in multiples of100 ms.
Default = 0x3C (6 seconds)
1
CS-SUP-MUTI-WPORTAPP-E04 68
