Coronis Wavenis Wavecard User Manual

Wavecard-Waveport User Manual Coronis Systems
Appendix II – Wavecard electronic interface
• 25mW WaveCard
PIN # PIN NAME DESCRIPTION INPUT / OUTPUT
1 TX TX RS232 signal OUTPUT
2 RX RX RS232 signal INPUT
3 RESET RESET input (active to high level, min.: 100 ms) INPUT
4 OUT2 Not used OUTPUT
5 OUT1 Output active (level 1) when reception is on OUTPUT
6 GND Ground OUTPUT
7 +3V OUT 3V regulated output voltage (10mA available) OUTPUT
8
SUPPLY
VOLTAGE
Input supply voltage (3.3V to 4.5V)
Minimum current 45mA
INPUT
• 500mW WaveCard
PIN # PIN NAME DESCRIPTION INPUT / OUTPUT
1 TX
TX RS232 signal (0 ;+2.7Vmax)
OUTPUT
2 RX
RX RS232 signal (0 ;+2.7Vmax)
INPUT
3 RESET RESET input (active to high level, min. 100 ms) INPUT
4 OUT2 Not used OUTPUT
5 OUT1 Output active (high level) when periodic reception is on OUTPUT
6 GND Ground OUTPUT
7 +2,7V OUT 2.7V regulated output voltage (10mA available) OUTPUT
8
SUPPLY
VOLTAGE
Input supply voltage [3,3V à 4,3V]
• 700mA minimum current peak
INPUT
CS-SUP-MUTI-WPORTAPP-E04 67
