Wavecard-Waveport User Manual Coronis Systems
Appendix IV – Parameter setting commands
CMD Name Description
0x40 REQ_WRITE_RADIO_PARAM Request to update radio parameters
0x41 RES_WRITE_RADIO_PARAM Radio board response to radio parameter update
0x42 REQ_CHANGE_UART_BDRATE Request to update serial link baud rate
0x43
RES_CHANGE_UART_BAUDRA
TE
Radio board response to the serial link baud rate update. Serial link baud rate
is updated after has ended
0x44 REQ_CHANGE_TX_POWER
(1)
Request to update radio board transmission power
0x45 RES_CHANGE_TX_POWER
(1)
Radio board response to transmission power update
0x46
REQ_WRITE_AUTOCORR_STAT
E
Request to update WAVENIS RF ASIC RSSI threshold auto-correction state
0x47
RES_WRITE_AUTOCORR_STAT
E
Radio board response to WAVENIS RF ASIC auto-correction state update
0x50 REQ_READ_RADIO_PARAM Request to read radio parameters
0x51 RES_READ_RADIO_PARAM Radio board response to parameter reading request
0x54 REQ_READ_TX_POWER Request to read radio board transmission power
0x55 RES_READ_TX_POWER Radio board response to the transmission power reading
0x5A
REQ_READ_AUTOCORR_STAT
E
Request to read WAVENIS RF ASIC RSSI threshold auto-correction state
0x5B
RES_READ_AUTOCORR_STAT
E
Radio board response to WAVENIS RF ASIC auto-correction state reading.
0x60 REQ_SELECT_CHANNEL Request to select operating radio channel when FHSS is deselected
0x61 RES_SELECT_CHANNEL Response to channel selection request
0x62 REQ_READ_CHANNEL Request to read the operating radio channel when FHSS is deselected
0x63 RES_READ_CHANNEL Response to read channel request
0x64 REQ_SELECT_PHYCONFIG Request to select RF medium communication mode
0x65 RES_SELECT_PHYCONFIG Response to communication mode selection request
0x66 REQ_READ_PHYCONFIG Request to read RF medium communication mode
0x67 RES_READ_PHYCONFIG Response to communication mode read request
0x68 REQ_READ_REMOTE_RSSI Request to read RSSI level from remote module
0x69 RES_READ_REMOTE_RSSI Response to the read remote RSSI level request
0x6A REQ_READ_LOCAL_RSSI
Request to read the local Wavecard RSSI level via an exchange with a
remote module
0x6B RES_READ_LOCAL_RSSI Response to the read local RSSI level request
0xA0 REQ_FIRMWARE_VERSION Request to read radio board firmware version
0xA1 RES_FIRMWARE_VERSION Radio board response to firmware version reading
0xB0 MODE_TEST Switch Wavecard into a selected test mode
(1) : Commands available only on Wavecard 25mW radio board
CS-SUP-MUTI-WPORTAPP-E04 69
