Wavecard-Waveport User Manual Coronis Systems
Commands
CMD NAME DESCRIPTION
0x68 REQ_READ_REMOTE_RSSI Request to read RSSI level from remote module
0x69 RES_READ_REMOTE_RSSI Remote module response to RSSI level request
0x6A REQ_READ_LOCAL_RSSI
Request to read the Wavecard RSSI level by frame exchange with a
remote module.
0x6B RES_READ_LOCAL_RSSI Response to local RSSI level request
In command byte coding, response frames reuse the request command with the LSB bit set to 1.
3.3.8 RSSI command format
Request to read RSSI level of a remote module
This measurement gives the remote module's RSSI level.
• Request
REQ_READ_REMOTE_RSSI
HEADER CMD DATA CRC ETX
3 bytes 1 byte 6 bytes 2 bytes 1 byte
0xFF ; 0x02 ;
0x0A
0x68 Remote module radio address 0x03
• Response
RES_READ_REMOTE_RSSI
HEADER CMD DATA CRC ETX
3 bytes 1 byte 1 byte 2 bytes 1 byte
0xFF ; 0x02 ;
0x05
0x69
Value of RSSI level upon frame reception from
Wavecard
0x03
Request to read local module's RSSI level
This measurement gives the RSSI level of the local Wavecard by exchanging a frame with a remote module.
• Request
REQ_READ_LOCAL_RSSI
HEADER CMD DATA CRC ETX
3 bytes 1 byte 6 bytes 2 bytes 1 byte
0xFF ; 0x02 ;
0x0A
0x6A Radio address of the remote module 0x03
CS-SUP-MUTI-WPORTAPP-E04 32
