Wavecard-Waveport User Manual Coronis Systems
2.1.2 Request / response mechanism
Some exchanges require using a request/response mechanism. In this case, a high-level acknowledgement
(command prefix: RES) is initiated by the RF board following the request frame (command prefix: REQ) sent
by the host.
Request frames are identified by “REQ_XXX_XXX” (i.e.
REQ_SEND_FRAME)
High-level acknowledgement frames are identified by “RES_XXX_XXX”
(i.e. RES_SEND_FRAME).
In this example, the RECEIVED_FRAME frame is the response to the REQ_SEND_FRAME request. High-
level acknowledgement of the request is identified by the RES_SEND_FRAME frame.
CS-SUP-MUTI-WPORTAPP-E04 9
