Wavecard-Waveport User Manual Coronis Systems
Format of commands for selecting transmission power
• Request (host to Wavecard)
REQ_CHANGE_TX_POWER
HEADER CMD DATA CRC ETX
3 bytes 1 byte 1 byte 2 bytes 1 byte
0xFF ; 0x02 ; 0x05 0x44 Parameter value (0x0A, by default) 0x03
• Response (Wavecard to host)
RES_CHANGE_TX_POWER
HEADER CMD DATA CRC ETX
3 bytes 1 byte 1 byte 2 bytes 1 byte
0xFF ; 0x02 ; 0x05 0x45
Status
0x00 : Update OK
0x01 : Update error
0x03
Format of commands for reading transmission power
• Request (host to Wavecard)
REQ_READ_TX_POWER
HEADER CMD CRC ETX
3 bytes 1 byte 2 bytes 1 byte
0xFF ; 0x02 ; 0x04 0x54 0x03
• Response (Wavecard to host)
RES_READ_TX_POWER
HEADER CMD DATA CRC ETX
3 bytes 1 byte 1 byte 2 bytes 1 byte
0xFF ;
0x02 ;
0x05
0x55 Parameter value 0x03
When the Wavecard is reset, its power level is reset to the default value of 14 dBm
(0x0A).
