74 11 INTERFACE
Reading Command
Command
Function
Data unit
RLD<CR>
Reading test data
Leak rate unit
RRTO<CR>
Reading HH and LL
%
RBHI<CR>
Reading BAL_Hi limit (Multi-comparison DT1_Hi)
Leak rate unit
RBLO<CR>
Reading BAL_Lo limit (Multi-comparison DT1_Lo)
Leak rate unit
RDHI<CR>
Reading DET_Hi limit (Multi-comparison DT2_Hi)
Leak rate unit
RDLO<CR>
Reading DET_Lo limit (Multi-comparison DT2_Lo)
Leak rate unit
RDL1<CR>
Reading DL1timer
s
RCHG<CR>
Reading CHG timer (Multi-comparison CG1)
s
RDL2<CR>
Reading DL2 timer (Multi-comparison BL1)
s
RBAL<CR>
Reading BAL timer (Multi-comparison DT1)
s
RDET<CR>
Reading DET timer (Multi-comparison DT2)
s
RSTB<CR>
Reading STB timer (Multi-comparison CG2)
s
RDL3<CR>
Reading DL3 timer
s
REND<CR>
Reading END timer
s
RDBD<CR>
Reading Multi-comparison BL2 timer
s
RMDL<CR>
Reading Multi-comparison DL2 timer
s
RLKC<CR>
Reading leak coefficient (equivalent internal volume)
L
Writing Command
Command
Function
Unit
WCHN_00
Channel setting 00 to 15
WRTO 10<CR>
HH, LL 10 to 90 (Every 10)
%
WBHI ±0123.000<CR>
BAL_Hi limit (Multi-comparison DT1_Hi)
-0999.000 to +0999.000
Leak rate unit
WBLO ±0123.000<CR>
BAL_Lo limit (Multi-comparison DT1_Lo)
-0999.000 to +0999.000
Leak rate unit
WDHI ±0123.000<CR>
DET_Hi limit (Multi-comparison DT2_Hi)
-0999.000 to +0999.000
Leak rate unit
WDLO ±0123.000<CR>
DET_Lo limit (Multi-comparison DT2_LO)
-0999.000 to +0999.000
Leak rate unit
WDL1 0123.000<CR>
DL1 Charge delay timer
0000.100 to 0999.900
s
WCHG 0123.000<CR>
CHG Charge timer (Multi-comparison CG1)
0000.000 to 0999.900 *1
s
WDL2 0123.000<CR>
DL2 Balance delay timer (Multi-comparison BL1)
0000.100 to 0999.900
s
WBAL 0123.000<CR>
BAL Balance timer (Multi-comparison DT1)
0000.100 to 0999.900
s
WDET 0123.000<CR>
DET Detection timer (Multi-comparison DT2)
0000.100 to 0999.900
s
WSTB 0123.000<CR>
STB Stabilization timer (Multi-comparison CG2)
0000.000 to 0999.900 *1
s
WDL3 0123.000<CR>
DL3 End delay timer
0000.000 to 0999.900
s
WEND 0123.000<CR>
END End timer
0000.200 to 0999.900
s
WDBD 0123.000<CR>
Multi-comparison BL2 timer
0000.100 to 0999.900
s
WMDL 0123.000<CR>
Multi-comparison DL2 timer
0000.000 to 0999.900
s
WLKC 0123.000<CR>
leak coefficient (equivalent internal volume)
0000.000 to 0999.999
L
*1 When memory switch 24 is set to 0, the timers can be set in the range from 0000.000 to 9999.000.
When a value of 1000.000 or greater is set, the digits after the decimal point are truncated on the timers.
When a value of 6001.000 or greater is set, the timer values are infinite (9999.0).
