LEMCOM CANopen® – User manual Wiring instructions
COVAL – LMCOP-EN-A-1155UM0068 10/49
3 WIRING INSTRUCTIONS
- Connector type: M8 male
Figure 2 – Wiring a LEMC--X---W2GB4 island
3.1 CAN ports
A CAN interface is integrated in the LEMCOM (model W2) and features two CAN ports on the front
of the module.
Figure 3 – Wiring instructions (M8 – CAN bus ports)
