LEMCOM CANopen® – User manual LEMCOM Manager configuration utility
COVAL – LMCOP-EN-A-1155UM0068 15/49
5 LEMCOM MANAGER CONFIGURATION UTILITY
LEMCOM Manager is a user-friendly tool that helps to quickly and easily configure, monitor and
troubleshoot LEMCOM units.
The network parameters of the CANopen LEMCOM master module as well as all the operating
parameters of the LEMCOM modules in an island can be modified using the LEMCOM Manager PC
software available for download from the COVAL web site.
All the diagnostic data such as cycle counters, instant vacuum level, grip signal, product reference,
firmware version, power supply and more can be monitored through one single screen.
For CAN based LEMCOM unit, an IXXAT USB
CAN interface is required to connect the
LEMCOM module to the PC on which LEMCOM
Manager is running.
IXXAT item no.: 1.01.0281.12001
More information on the LEMCOM Manager
features can be found in the dedicated user
manual: LEMCOM-Manager-xx-x-1155UM0069
