page-10 EVOLUTION COVER
POSITION OF THE KEY SWITCH
WARNING
l
The key switch must be permanently installed and located 5 ft (1.5 m) away from the spa and 5 ft (1.5 m)
above the deck or ground level, see Figure 2.
l
Make sure the user has a clear view of the cover when operating it.
l
Furthermore, the key switch must be located in an area where no water downpour or debris might fall on it.
FIGURE 2: POSITION OF THE KEY SWITCH
240799 OWNER'S MANUAL REVISION 4
