page-56 EVOLUTION COVER
FIGURE 83: OPERATOR EXTENSION SHAFT
WARNING
Never use a power tool, as this will damage the
unit.
5.
Turn the extension shaft clockwise to lower
the cover and counterclockwise to raise the
cover.
WARNING
Do not exceed the limits of the mechanism. Failure
to respect this guideline may cause mechanical
failure.
6.
Reinstall the operator cover with the four
screws.
7.
Reconnect and turn on the power supply.
USING THE ESCAPE HATCH
FROM INSIDE THE SPA
1.
Turn the red handle by a quarter turn in either
direction to retract the arms, see Figure 84.
FIGURE 84: INSIDE HANDLE
2.
Push straight up on the escape hatch and
move it to the side, see Figure 85.
FIGURE 85: REMOVE HATCH
3.
Escape via the hole and call for assistance if
required.
FROM OUTSIDE THE SPA
1.
Never step on the escape hatch as it may
affect the removal and may jeopardize the life
of the persons trapped in the spa.
2.
Turn handle one quarter turn in either
direction.
3.
Lift the escape hatch straight up by gripping
its sides and move it to the side.
4.
Help the persons trapped below by pulling
them out of the spa via the opening.
240799 OWNER'S MANUAL REVISION 4
