page-14 EVOLUTION COVER
GLOSSARY
PART IMAGE FUNCTION
Sleeve all-weather seal
This all-weather seal protects sleeves from damage due
to weather.
Contour seal
The contour seal makes sure there is uniform contact
between the cover panels and the spa.
Contour seal installation
clip
Contour seal installation clips are used during the
installation process to make sure the seal is installed
properly.
Contour seal connector
The seal connector is used to link both ends of the
contour seal.
Outer corner bracket The outer corner bracket fastens the cover to the sleeves.
Drive shaft
The drive shaft transmits the power from the operator to
the non-motor-side jacks.
240799 OWNER'S MANUAL REVISION 4
