Bipolar Controls
Controls, Indicators,
and Receptacles
Force FX Electrosurgical Generator C Service Manual 2-3
Bipolar Controls
Buttons and indicators for bipolar controls
Bipolar indicator
When you activate bipolar, this
indicator illuminates blue and
an activation tone sounds.
Power buttons
Press
to increase the power.
Press
to decrease the power.
Macro mode button
Select for macrobipolar output.
Standard mode button
Select for standard bipolar tissue
desiccation. This is the default
bipolar mode.
Precise mode button
Select for fine bipolar
tissue desiccation.
Bipolar display
Shows the power setting,
in watts, for the selected
mode.
Mode indicators
Illuminate green when
you press the
corresponding mode
button.
