Covidien Force FX - Expansion Port; Low Frequency (50-60 Hz) Leakage Current; High Frequency (RF) Leakage Current

Performance Characteristics
Technical Specifications
Force FX Electrosurgical Generator C Service Manual 3-7
Expansion Port
Low Frequency (50–60 Hz) Leakage Current
High Frequency (RF) Leakage Current
15-pin connector;
supports the
following signals
• Pin 2–isolated transmit
(serial data output transmit line)
• Pin 3–isolated receive
(serial data input receive line)
• Pin 5–isolated ground
(reference for transmit and receive)
• Pin 9–RF disable: input signal which, when activated
by an external device, disables active RF output
• Pin 10–RF current: output signal proportional to
active RF current
• Pin 11–RF voltage: output signal proportional to
active RF voltage.
Expansion power
(from the low voltage
power supply)
+ 5 V (pin 6),-12 V (pin 14), + 12 V (pin 15), and
ground (pins 12 & 13)
Enclosure source
current, ground open
< 300 μA
Source current,
patient leads, all
outputs
Normal polarity, intact ground: < 10 μA
Normal polarity, ground open: < 50 μA
Reverse polarity, ground open: < 50 μA
Sink current at high
line, all inputs
< 50 μA
Bipolar RF leakage
current
< 59.2 mA
rms
Monopolar RF leakage
current
(additional tolerance)
< 150 mA
rms
CEM output modes < 150 mA
rms
at  50 W
