Covidien Force FX - Parts List

Generator Assembly
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-5
Parts List
Item Description Part Number
1 Chassis, lower 1081476
2 Assembly, Footswitch board
See Footswitch Board Components in this section.
1052932
3 Cable assembly, line filter
Includes
Cable, filter line ground
Cable, filter line
Tubing, heatshrink black 1/4 ID
Line filter, 10 amp
Fuse, 8A, 5x20 mm Slow Blow
202 701 890
207 500 723
207 500 543
249 001 002
251 400 007
215 100 070
4 Handle, collapsible tray 223 300 054
6 Equipotential ground lug 208 200 141
8 Screw, Phillips M4 x 0.7 x 10 237 050 139
9 Sealant, loctite #222 232 301 148
10 Screw, panhead Phillips M4 x 0.7 x 8 mm 237 050 113
11 Washer, lock internal metric M4 253 300 045
12 Screw, panhead Phillips M3 x 0.5 x 12 zinc 237 050 135
13 Washer, lock internal metric M3 253 300 044
14 Screw, panhead M3 x 0.5 x 8 zinc 237 050 149
15 Lockwasher, M6 ext tooth 253 300 000
16 Nut, hex M6 x 10 brass nickel plated 224 300 000
21 Assembly, front panel
See Front Panel Assembly on page 9-7.
1081734 / 1080592
BCMA / SHMA
22 Assembly, Programmed control board
See Control Board Components on page 9-10.
1081721
23 Cover, upper 1012587 / 1032764
BCMA / SHMA
