Covidien Force FX - Footswitch Board Components

Footswitch Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-13
Footswitch Board Components
Reference
Designator Description Part Number
Capacitors
C38, C47, C48,
C49
CAP CER 1000 PF 100 V 10% X7R SMD 0603 1078188
C2, C14, C16,
C18
CAP CER 0.01 µF 100 V 10% X7R SMD 0603 1078154
C3, C4, C5, C6,
C7, C12, C13,
C15, C17, C20,
C21, C22, C24,
C26, C28, C29,
C30, C31, C32,
C33, C36, C45,
C50
CAP CER 0.1 µF 100 V 10% X7S SMD 0603 1078183
C1 CAP CER 4.7 µF 25 V 10% X5R SMD 0805 1078182
C39, C40, C41,
C42, C43, C51
CAP MICA 30 PF 100 V 5% SMD 0805 1078179
C8, C19, C23,
C25, C34, C37
CAP CER 0.1µF 100 V 10% X7R SMD 0805 1078184
C44 CAP CER 2200 PF 100 V 10% X7R SMD 0805 1078189
C46 CAP CER 1 µF 25 V 10% X5R SMD 0805 1078190
C52 CAP CER 0.1 µF 50 V 10% X7R SMD 0805 1078191
C9, C10, C27 CAP TANT 22 µF 25 V 20% SMD D CASE 1078185
C11 CAP CER 1 µF 50 V 20% X7R SMD 0805 1078186
C35 P CER 0.022 µF 100 V 10% X7R SMD 0805 1078187
Diodes
D1, D2 DIODE SWITCH 100 V 0.15 A SOD 123 1078289
D3, D4, D5 TVS DIODE 5.5 VWM SOT 143 1078192
D6 DIODE ZENER 15 V 500 MW SOD 123 1078193
Transistors
