Footswitch Board Components
9-14 Force FX Electrosurgical Generator C Service Manual
Q1 TTL MOSFET N-CHANNEL 240 VDS TN2404KL 1042981
Resistors
R1, R2, R3, R4,
R7, R9
RES THICK FILM 1206 10 K
 5% SMD 1078196
R5, R31 RES THICK FILM 1210 10.0 K
 1% SMD 1078197
R6 RES THICK FILM 1206 6.8 K
 5% SMD 1078198
R8, R15, R22,
R23, R26, R29
RES THICK FILM 1206 2 K
 5% SMD 1078199
R10 RES THICK FILM 1210 33.2 K
 1% SMD 1078200
R11 RES THICK FILM 1210 432
 1% SMD 1078201
R12 Pot, 5 k
 1042215
R13, R16, R20,
R24, R27
RES THICK FILM 1210 1.40 K
 1% SMD 1078202
R14, R17, R18,
R19, R21, R25,
R28, R56
RES THICK FILM 1210 2.15 K
1% SMD  1078203
R30 RES THICK FILM 1210 19.6 K 1% SMD 1078204
R32 RES THICK FILM 1210 200 K
1% 1078268
R33 RES THICK FILM 1210 5.11 K
 1% SMD 1078269
R34 RES THICK FILM 1206 56 K
 5% SMD 1078270
R35 RES THICK FILM 1206 100 K
 5% SMD 1078271
R37, R38, R39,
R40, R41, R43,
R48, R53
VARISTOR 24 V 0603 1078180
R36 RES THICK FILM 1206 1.20 K
1% SMD 1078272
R42 RES 0805 1.00 K 1%
 SMD 1078273
R44, R46, R49,
R51, R54
RES THICK FILM 0603 7.50 K
1% SMD 1078274
Reference
Designator Description Part Number
