Control Board Components
9-10 Force FX Electrosurgical Generator C Service Manual
Control Board Components
Display Board Components
Reference
Designator Description Part Number
1 Effect mode controller PCB 1052935
Reference
Designator Description Part Number
Capacitors
C1, C2 CAP CER 0.01 µF 50 V 10% X7R SMD 0603 1078153
C3, C4, C5, C6, C10 CAP CER 0.1 µF 50 V 10% X7R SMD 0603 1078164
C7, C8, C9 CAP TANT 47 µF 20 V 20% SMD D CASE 1078170
C11, C12, C13, C14,
C15, C16, C17, C18,
C19, C20, C21, C43,
C44, C45, C46, C47,
C48, C49, C50, C51,
C52, C53
CAP MICA 30 PF 100 V 5% SMD 0805 1078179
C22, C23, C24, C25,
C26, C27, C31, C32,
C35, C36, C37, C38,
C39, C40, C41, C42
CAP CER 240PF 50 V 5% NPO SMD 0603 1078168
C28, C29, C30, C33, C34 CAP CER 0.01 µF 100 V 10% X7R SMD 0603 1078154
LEDs and Lamps
D1 LED GRN 0.2 DIA 1041644
LP1, LP2, LP3, LP4, LP5,
LP6, LP7, LP8, LP9, LP10,
LP11, LP12
Lamp 1041648
Transistors
Q1, Q2, Q3 XSTR FET N-CHAN 100 V 1A 1042942
