Covidien Force FX - Parts List

Front Panel Assembly
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-9
Parts List
Item Description Part Number
4 Switch 243 025 037
5 Tubing, heatshrink 1 inch ID 249 001 010
6 Bipolar bracket 223 500 077
7 Tape, foam one-sided 1/16 x 1/4 232 301 185
8 Cable assembly, REM 1049479
9 REM retaining plate 1049490 /
1076223
10 Screw, panhead Phillips M3 x 0.5 x 12 zinc 237 050 135
11 Washer, lock internal metric M3 253 300 044
12 Assembly, Display board
See Display Board Components on page 9-10.
1058979
13 Screw, thread forming #4-20 0.625 237 050 147
14 Display board spacer 223 400 626
15 Cable assembly, power switch 207 500 213
16 Shroud, bipolar 223 100 998
17 Assembly, CEM switch S1052008
18 Adhesive, prism 411 232 301 004
19 Washer, flat M3 253 300 004
Not shown
Overlay jack 1049875
Keyboard front 1012634
Control panel 223 200 667
