Footswitch Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-15
R45, R47, R50,
R52, R55
RES THICK FILM 0603 4.99 K 1% SMD 1078275
R57 RES THICK FILM 0603 10.0
1% SMD 1078276
Integrated Circuits
U1 IC COMPARATOR QUAD 15 V / 30 V 14-PIN SOIC 1078277
U2 CNVTR DC/DC HPR107 1047294
U3, U4, U5 IC COMPARATOR DUAL 18 V / 36 V 8-PIN SOIC 1078278
U6 IC OP AMP DUAL GP 16 V / 32 V 8-PIN SOIC 1078279
U7 IC AUDIO AMP SPEAKER 8-PIN SOIC 1078287
Miscellaneous
ISO1, ISO2, ISO3,
ISO4, ISO5
IC OPTOCOUPLER TRANSISTOR 1078288
SP1 SPKR 8
1047286
Not shown
SPCR FTSW FORCE X 1047287
CABLE 10-IN TWISTED PAIR 20-WIRE RIBBON 1078514
SCR PNH M3 10 MM 1047291
WSHR FLAT M3.01 1045722
WSHR E.T. M3 STL 1047292
NUT HEX STL ZINC PLD M3X0.5 1047290
W TEF 24 AWG WHT 1047293
Reference
Designator Description
Part Number
