Power Supply/RF Board Assembly
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-19
20 ASSEMBLY, HEAT SINK, OUTPUT (right)
Includes
CABLE ASSEMBLY, RESISTOR
WASHER, SHOULDER
RIGHT HEAT SINK
PCB FET
SCREW, PNH PHH M4 x 0.7 x 8 mm
SCREW, PNH PHILLIPS M3 x 0.5 x 12 ZINC
TRANSISTOR FET BUZ80A
TRANSISTOR FET HI-V N-CH
DIODE, ULTRA FAST 30 A, 1000 V
WASHER, LOCK INTERNAL METRIC M4
1078630
1045737
1045743
1078633
1052506
1049780
1049782
1042978
1045740
1042335
1049779
21 ASSEMBLY, HEAT SINK, HIGH VOLTAGE (left rear)
Includes
CABLE ASSEMBLY, RECTIFIER
WASHER, SHOULDER
LEFT REAR HEAT SINK
RESISTOR, MF 150
 ± 5%, 20 W
SCREW, PANHEAD PHILLIPS M3 x 0.5 x 12 ZINC
TRANSISTOR FET N-CH 8 A, 500 V
DIODE BRIDE 35 A, 400 V
WASHER, FLATM3.0
WASHER, LOCK INTERNAL M3
1078311
1045723
1045724
1078313
1042270
1049782
1042350
1045714
1045722
1049776
22 ASSEMBLY, HEAT SINK, RECTIFIER (left front)
Includes
WASHER, SHOULDER
LEFT FRONT HEAT SINK
RESISTOR, MF 150
 ± 5%, 20 W
SCREW, PANHEAD PHILLIPS M2.5 x 04.5 x 10 mm ZINC
DIODE, FAST RECOVERY
1078315
1045724
1078316
1042270
1045720
1045748
23 PANHEAD PHILLIPS M4 x 0.7 x 20 mm 1049726
24 FUSE HOLDER 1049706
25 BRACKET, HEAT SINK SUPPORT 1052548
28 SCREW, PANHEAD PHILLIPS M4 x 0.7 x 8 NYLON 1049727
30 WIRE, TS, 20 AWG, YELLOW 1049731
31 SLEEVING, PVC CLEAR 11 AWG 1049733
32 WIRE, TS, 20 AWG, RED 1049732
33 WASHER, LOCK INTERNAL M3 1049776
Item Description Part Number
