MAINTENANCE (Cont’d)
The internal pressure transducers are used during recovery, vacuum, air purge and in the manifold mode. Access this
menu if you suspect that the internal pressure transducer readings are inaccurate.
- Calibration will require a certified pressure source above 70 PSIG.
- Follow the displayed direction for the select transducer maintenance function.
- Select Maintenance Mode for Pressure Transducer.
PRESSURE TRANSDUCER (Tare Or Calibrate)
(Not All Screens Are Shown)
a. On the Maintenance Screen, touch .
1
a. Touch either the “Tare” or “Calibrate”
keys.
2
a. Wait while PT1 zeros out.a. Touch to “Tare” (zero out) the Pressure
Transducer (PT).
43
Zero The Pressure Transducer Zero The Pressure Transducer
Tare (Zero) The Pressure Transducer
(Not All Screens Are Shown)
Actual scale calibration is suggested only if the calibration test was off by more than .02lbs. Calibration may
be performed by a CPS authorized service center. CPS Technical Support can also assist with the process.
Scale calibration requires a certified 25lb weight.
7
Note: The scale is powered by the MX machine (no batteries to replace)
